Hardware:

Display: 8" TFT LCD
        Multi-touch Capacitive
                800x600 Resolution
SoC: Freescale ARM Cortex A8 800MHz
Chipsets: MCIMX515D
Memory: 512MB DDRII (support up to 1GB)
Storage: 4GB Standard (support up to 16GB)
WiFi: 802.11b/g WiFi (802.11n Optional)
3G: WCDMA / EVDO
        Quad-band EDGE/GPRS/GSM850/900/1800/1900M
        HSUPA uplink up to 2.0 Mbps, HSDPA downlink up to 7.2 Mbps
        GSM+3G Audio SMS and Data service simultaneously
BT: Bluetooth 3.0 + High Speed (HS) (Optional)
GPS: Single-conversion low-IF GPS receiver for the
        1.575GHz, L1 signal (Optional)
Camera: High quality 2M pixel CMOS image sensor
        1644 x 1260 pixel array
Sensor: G-Sensor, L-Sensor
Audio: 1x3.5mm Stereo Earphone, Built-in Microphone
        Built-in speakers
I/O: 1xMini USB, 1xTF Card, 1xSIM Card
Power: 4500mAh, 100 hours standby,
        8 hours continuous

• Accessories:
  Universal AC Adaptor
  USB Cable

• Dimension & Weight:
  210.5(L)x160.5(W)x14.7(H)mm
  0.57kg
• Software:
  Android 2.3

Freescale processor

With the iMX51, designers have access to key features needed for the end design offering hardware functionality and connectivity required for developing many applications. With production-ready software components, an optimized OS and a system-validated BSP, designers have the tools to test and maximize the performance of the applications they have developed. Explore multiple connectivity options with the iMX51 application processor: display, touch screen, USB, SDIO, Ethernet and others.

GPS

Best-in-class acquisition and tracking sensitivity, TTFF and accuracy 158 dBm acquisition-assisted, -160 dBm track using internal LANs Advanced proprietary multipath algorithms for robust low-dropout tracking in indoor and very low signal environments. Supports GSM, WCDMA and CDMA control plane A-GPS assistance data standards. Supports SUPL user plane A-GPS assistance data. Exceeds 3GPP and TIA performance requirements. Temperature range-40℃ to +85℃.

Capacitive Multi-touch screen

Extremely Low Power Consumption: 23uA@1.8V 8kSPS Compatible with a Wide Range of 4-wire Resistive Touchscreen for Single/Multi-touch Operation. Integrated Preprocessing Block to Reduce Host Loading and Bus Activity. Four User Programmable Operation Modes provides Flexibility to address Different Application Needs Manual, Automatic, Pen Detect, Pen Trigger. Low Noise Ratiometric Conversion. Selectable Polling or Interrupt Modes. Touch Pressure Measurement.

4:3 Compatible with digital camera photographs

8" TFT Ultra-bright LCD
800x600 Resolution
4:3 Fullscreen display photos from digital camera

Long standby power usage

4500mAh
Power consumption 6mW
100 hours standby
8 hours continuous playback

I-See-U-On

3G

2D/3D Games

Hardware
CPU	Freescale iMX525 + Qualcom 3G Module
GPS RF	GLONAV7560
Displaly	Transmissive LCD panel
Scree Size	8"
Panel Brand	N/A
Resolution	800x600 Pixels
Brightness	400cd/m2
Back Light	Adjustable
On board Button/Keys	On/Off,Home,Volume,Backspace,Search,Menu
Sound System	1W 80hm built0in speaker
Features
Cold Startup Time	90sec
Warm Startup Time	38sec
Satellite Reacquisition	< 5sec
3G Quad-band	EDGE/GPRS/GSM850/900/1800/1900M
Internal Antenna	Built-in internal antenna
Position Accuracy	Within 10m
GPS Receiver	L1(1575.42Mhz),C/A code(1.023Mhz)
Touch Screen Navigation	Yes
Input Method	Stylus pen/software keyboard
Maximum Altitude	< 40,000 feet
Maximum Velocity	< 700 knots
CPU Speed	800MHZ
Operating Temperature	-20'C to 60'C
Storage Temperature	-25'C to 70'C
WAAS Function	Available
Camera	Yes(2M)
WiFi	Yes(802.11 b/g/n)
BT	Yes(Bluetooth 3.0 + High Speed)
G-Sensor	Yes(360 degree)
Multi-Touch	Yes(Capacitive Multi-Touch)
USB	Yes(USB 2.0 HOST)
3G	Yes(WCDMA/EVDO)
L-Sensor	Yes(light strength 0-4K Lux)
Software
Operating System	Android 2.3
Fireware upgrade	Flash Eprom filed programming softeare available
Time Mark	Output 1 pulse/sec,aligned with GPS time ± 1u sec
OSD Menu	English Multi-language
Office	WORD EXCEL PDF TXT
Instant Messaging	QQ MSN SKYPE E-mail
Other Functions	Game/E-book/Music on line/CCTV/ Youtube/Google map
Internet Browser	internet Explorer
Voice Navigation	yes
Power Supply
AC/DC	AC 110-240V 50/60Hz; DC 5V/2.5A
Built-in Battery	Li-polymer Rechargeable Battery 4500mAh

Map
Engine	As per customer's request
Map Data	TA or Navtaq
Points of interset	Depending on target country
Coverage	Depending on target country
Media Function
Audio Support	MP3,WMA,FLAC,APP,OGG...(all format audio support)
Photo Viewer	JPG,BMP,PNG,GIF,TIFF...
Video Support	Mpeg4,Mpeg2,Vc1,Rv10,asp,divx,H.263,H.264/720P,Mjpeg (All format video support)
Memory
Internal Memory-RAM	512MB DDR2 (support up to 1GB)
Internal Memory-ROM	4GB standard(support up to 16GB)
External Memory/Format	Micro SD Card Slot,Support up to 32GB flash
Expand Card	SIM Card
Connection
AC/DC Jack	Yes
Headphone	Yes
USB connection	Mini USB
Accessories
User's Manual	Optional
Quick Setup Quide	Optional
Installation CD	Optional
USB cable	Yes
Leather	Optional
Micro SD Memory Card	Optional
Carry Bag	Optional
AC/DC Power Adapter	Yes
Shipping Details
Unit Dimension (LxWxH)	210.5(L)x160.5(W)x14.7(H)mm
Unit N.W.	0.57kg
Giftbox Dimension (LxWxH)	225(L)x200(W)x65(H)mm
Giftbox G.W.	0.96kg
Carton Dimension (WxDxH)	To be advised
Carton G.W.	To be advised
Loading QTY	To be advised
Certification requirements
3C
CE
FCC
UL
